Fiber Optic Pigtail MultiMode OM3 12 Core PT201

Fiber Optic Pigtail — Multimode (MMF 50/125 μm – OM3) – SC 12-Core Color Bundle

Features
Outer jacket made of high-quality, eco-friendly PVC — durable and sturdy
Excellent fiber processing for stable connection performance
Good repeatability and high stability
Ceramic ferrule for low insertion loss and good return loss
Suitable for Telecommunications, Unifi, LAN, FTTH (indoor MM links), optical sensors, test instruments, etc.
Low insertion loss
Easy to handle
High quality
Color-coded (12 colors)
Meets Telcordia GR-326 Core and RoHS requirements

Optical Type
Multimode (MMF 50/125 μm) — OM3 compatible
Typical IL: ≤ 0.3 dB (per connector)
Return Loss: ≥ 35 dB (PC on MM)
Fiber Standard: G.651.1 (50/125 μm)
Colors: 12-color bundle
Compliant: RoHS, ISO9001
Wavelengths: 850 / 1300 nm

Specification
Item Type: Fiber Pigtail Cable SC 12-core bundle (multimode)
Working Wavelength: 850 / 1300 nm
Pigtail Length: 1.5 meters (each piece)
Grade: Carrier-class
Jumper Mode: Multimode
Minimum Bend Radius: 3.8 cm
Attenuation (per pigtail): < 1 dB (field guide)
Ferrule: Ceramic
Outer Material: High-quality, eco-friendly PVC

Advantages
Manufacturer source
10+ years production experience
100% tested
Low insertion loss
High return loss (MM PC ≥35 dB)

Consists of
1 pack = 12 pcs SC Multimode color pigtails, 1.5 m each
