AI-8C Fiber Optic Welding Splicing Machine Optical Fiber Fusion Splicer Fully Automatic Signal Fire Ai 8c SM101

– Specifications :
Fiber alignment:Core/cladding alignment / Manual alignment
Splicing time:6S(Ai-8)
Heating time:Automatic heatingPreheating
Focus mode:Six motors Auto focus
Applicable Fibers:SM(G.652&G.657)、MM(G.651)DS(G.657)、NZDS(G.655)
Splice Loss:0.025dBSM、0.01dBMM、 0.04dBDS/NZDS
Control technology:Real-time control and calibration of fusion ARC
Return loss:Better than 60DB
Fiber diameter:Cladding Diameter(80-150μm)、Coating Diameter(100-1000μm)
Fiber Cleave Length:Coating less than 250μm(8-16mm)、Coating less than 250-1000μm16mm
Built-in lightingeasy for night operation
Tension Test:Standard 2N
Fiber holders:3 in 1 fiber holder, SM, MM, bare fiber, pigtail,rubber-insulated, multi fiber cable
Magnification:300 for X or Y view, 150 for X or Y view
Screen:5 inch TFT color display
Splicing Mode:Normal / high precision splicing
Splicing record storage:Synchronize to the phone, the server to cloud storage unlimited
Built-in battery:7800 mA high-capacity lithium battery, charging time ≤ 3.5 hours, continuous splicing and heating about 200 times
Power supply:Input AC100-240V 50 / 60HZ, output DC13.5V / 4A, the current power mode can be identified,real-time detection of battery power
Operating Conditions:Temperature -15 ~ +50 ℃, humidity: <95% RH (no condensation)
Working altitude: 0 5000m. Resist max. wind speed: ≤ 15m / s
Shrinkable tube:60mm、40mm
Size:130mm*122*148
