OM4 DUPLEX Multimode Fiber Patch Cord Cable FC/UPC-SC/UPC 2.0mm AQUA (1|2|3|5|10M) PCM201

🔵 Patch Cord OM4 2.0mm Duplex

FC/UPC-LC/UPC | FC/UPC-FC/UPC | FC/UPC-SC/UPC

Premium grade OM4 Multimode Fiber Patch Cord (50/125μm) designed for ultra-high bandwidth and stable high-speed transmission in data centers and enterprise networks.

Ideal for 10G / 40G / 100G network applications.

✅ Product Features

✔️ OM4 Multimode (50/125μm)
✔️ Duplex (2 Core)
✔️ 2.0mm Strong & Flexible Jacket
✔️ Low Insertion Loss
✔️ High Return Loss
✔️ Precision Ceramic Ferrule
✔️ Stable Signal Performance
✔️ 100% Factory Tested

🔧 Available Connector Options

• FC/UPC – LC/UPC Duplex
• FC/UPC – FC/UPC Duplex
• FC/UPC – SC/UPC Duplex

(Please select correct variation before checkout)

📊 Technical Specifications

• Fiber Type: OM4 Multimode
• Core Size: 50/125μm
• Polish Type: UPC
• Cable Diameter: 2.0mm
• Wavelength: 850nm / 1300nm
• Jacket Color: Violet (OM4 Standard)
• Operating Temperature: -20°C to +70°C

🚀 OM4 Advantage

Compared to OM3, OM4 supports:

✔️ Higher bandwidth
✔️ Longer transmission distance
✔️ Better performance for 40G & 100G network
✔️ More future-proof infrastructure

🎯 Application

✔️ Data Center
✔️ High Speed Switch to Patch Panel
✔️ Enterprise LAN
✔️ FTTH Network Room
✔️ Server Rack Installation
✔️ Telecom Equipment Connection

📦 Package Includes

• 1 x OM4 Duplex Patch Cord
• Dust Protection Caps

⚠️ Important Notes

• For Multimode equipment only
• Not compatible with Single Mode (OS2)
• Please confirm connector type before purchase
